Power Output

Channel 1 & 2 & 3 & 4 (8Ω): 4 x 400W

Channel 1 & 2 & 3 & 4 (4Ω): 4 x 600W

Damping Factor (20Hz ~ 400Hz @ 8Ω): > 250

Slew Rate (1KHz @ 2 x 4Ω): 6.5V / uS

• Frequency Response: 10Hz ~ 50KHz (-2 dB)

THD + Noise: 0.1%

S/N Ratio: -86 dBm

Noise Floor: 3 mV

Total Gain: 40 dB

• Amplifier Protection: Four variable speed fans for cooling;

Power On/Off relay; RF protection; DC offset protection circuits;

thermal overload protection; short circuit protection.

Input Section

• Input Impedance balanced / unbalanced: 40KΩ/20KΩ

Sensitivity (level control set to max)

   balanced/ unbalanced: -3.8 dBm, 500 mV/ +2.2 dBm, 1V

Max Input Level (Level control set to Mid): >5V, +16.2 dBm

• LED Indicators

Signal: 4 x Green LED

Clipping: 4 x Red LED

Protect: 4 x Red LED

 Power On: 1 x Blue LED

• GENERAL

Power Requirements: 110V AC/60Hz

Fuse Requirements: F25A 250V

Weight: 22.5kg (49.6 lbs)

Dimensions (WxHxD): 483 x 88.8 x 436mm
