KICKER Tweeter 49ST3TW ST3TW 1" 4OHMS KICKER Tweeter 49ST3TW ST3TW 1" 4OHMS

KICKER Tweeter 49ST3TW ST3TW 1" 4OHMS

G$18,190.00

ST3TW
1" Tweeter 4

PA Style, High Output



  • Extremely efficient, horn-loaded aluminum diaphragm for extreme output
  • Single-unit, PA-style tweeter perfect for competition-level SPL systems
  • Voiced for clear vocals to match with high-output bass
  • Includes front or rear mount options, in addition to trim bezel options
  • Spring-loaded terminals accept 16 AWG wire
  • In-line 6dB crossover
  • Field-replaceable voice-coil assembly available (ST3RK/ST4RK)
Specifications
SingleTweeter [in, mm]
1, 25
Dome Material
aluminum
Design
bullet
Impedance [Ohms]
4
Recommended Amp Power [watts RMS]
15-50
Peak Power Handling [watts]
100
Frequency Response [Hz]
3.5k-20k
Sensitivity [1W, 1m]
106
In-Line Crossover [dB]
6, high-pass
Mounting Depth [in, mm]
1-3/16, 30
Mounting Diameter [in, mm]
2-5/16, 58
Thread Length [in, mm]
1-1/16, 27
Thread Diameter [in, mm]
1-11/16, 43
What's in the box?
1 - 3" ST tweeter
1 - 3" ST Round Mounting Flange
1 - 3" ST Backing Nut
1 - 3" ST Square Mounting Flange
4 - Mounting Screws
1 - Capacito
1 - Resistor
